小波纹手轮
 |  | JB/T7273.1-94
(GB4141.20-84 JB1351-73) d | D | H | h | 8 | 63 | 20 | 14 | 10 | 80 | 24 | 16 | 12 | 100 | 28 | 18 | 12 | 125 | 32 | 20 |
|
小手轮
 |  | JB/T7273.2-94
(GB4141.21-84 JB1352-73)
d | D | H | 10 | 80 | 32 | 12 | 100 | 36 | 12 | 125 | 40 |
|
镀铬手轮
|  | JB/T7273.3-94
(GB4141.22-84 JB1353-73)
D | d | H | 100 | 12 | 32 | 125 | 12 | 36 | 160 | 15 16 | 40 | 200 | 18 20 | 45 | 250 | 22 25 | 50 |
注：键槽按GB1095-79规定 |
波纹镀铬手轮
 | | GB4141.23-84
(JB1353-73)
D | d | H | 160 | 16 | 40 | 200 | 18 20 | 45 | 250 | 22.25 | 50 | 320 | 25.28 | 55 | 400 | 28.32 | 60 |
|
圆轮缘手轮
 |  | JB/T7273.5-94
(GB4141.24-84 JB1356-73)
D | d | 100 | 12 | 125 | 12 | 160 | 16 | 200 | 18 20 | 250 | 22 25 | | 280 | 25 30 | | 300 | 25 30 | | 400 | 30 35 |
注：键槽按GB1095-79规定 |
内波纹手轮
 |
| JB/T7273.7-94(JB3717.10-85)
d | D | h | B | H | L | 12 | 100 | 18 | 26 | 41 | 50 | 125 | 30 | 44 | 63 | 16 | 160 | 20 | 32 | 54 | 80 | 18 | 200 | 25 | 34 | 56 |
注：L为手柄长度，
键槽按GB1095-79规定 |
背面波纹手轮
 |  | | JB/T7273.8-94(JB3717.9-85) | d | D | h | B | H | L | 10 | 80 | 16 | 12 | 22 | 50 | 12 | 100 | 18 | 14 | 28 | 63 | 12 | 125 | 18 | 16 | 32 | 16 | 160 | 20 | 18 | 38 | 80 | 18 | 200 | 25 | 20 | 44 | 22 | 250 | 28 | 25 | 52 | 100 |
|
注：L为手柄长度，
键槽按GB1095-79规定 |
带可折手柄双幅条手轮
 |  | JB/T7273.10-94(JB3717.12-85)
d | D | H | h | B | L | 12 | 100 | 42 | 18 | 20 | 50 | | 125 | 45 | 22 | 63 | 16 | 160 | 48 | 20 | 25 | 80 | 18 | 200 | 54 | 25 | 28 |
注：键槽按GB1095-79规定 |
双柄手轮
 |  | JB3717.15-85(Z55-2)
d | D | H | h | B | L1 | L2 | 8 | 63 | 20 | 16 | 12 | 50 | 32 | 10 | 80 | 22 | 12 | 100 | 28 | 18 | 14 | 63 | 36 |
注：键槽按GB1095-79规定 |
满幅手轮
 |  | QB8251.6-98
D | d | B | h | 160 | 16 | 59 | 34 | 180 | 16 | 59 | 36 | | 240 | 24 | 120 | 100 |
注：主要用于印刷机械 |
铣床手轮
 | | B1Z52-8:200 B1Z52-8:250 D | d | d1 | 备注 | 200 | 30 | 22 | 通用
X62W X52K | 250 | 30 | 22 | 通用
X63W X53K |
名称 | 技术规格 | 备注 | 分度盘 | 4501 | 铣床通用 | 大把手 | 4502 | 铣床通用 | 刻度盘 | 586 | 铣床通用 |
|
带可折手柄注塑轮
 | | |
把手
 |  | JB/T7274.1-94
(GB4141.26-84 JB1357-73)
| d | D | L | | M5 | 16 | 9 | | M6 | 20 | 10 | | M6 | 25 | 10 | | M8 | 32 | 14 | | M10 | 40 | 16 |
|
压花把手
 |  | JB/T7274.2-94
(GB4141.27-84 JB1358-73)
| d | D | L | | 6 | M6 | 25 | | 8 | M8 | 32 | | 10 | M10 | 40 | | 12 | M12 | 50 |
|
十字把手
 |  | JB/T7274.3-94(
GB4141.28-84 JB1359-73)
|
星型把手
 |  | JB/T7274.4-94
(GB4141.29-84 JB1360-73)
| d | d1 | D | | 6 | M6 | 25 | | 8 | M8 | 32 | | 10 | M10 | 40 | | 12 | M12 | 50 | | 16 | M16 | 63 | | 16 | M16 | 80 |
|
Ｔ型把手
 |
 | JB/T7274.6-94
(JB3717.16-85)
| d | d1 | L | d2 | l1 | l | | 6 | M6 | 70 | 2 | 16 | 24 | | 8 | M8 | 80 | 3 | 25 | 44 | | 10 | M10 | 90 | 3 | 28 | 48 |
|
三角箭形把手
 |  | JB/T7274.8-94
(JB3717.19-85)
| d | D | d1 | h | h1 | | 10 | 80 | 3 | 25 | 32 | | 12 | 100 | 4 | 30 | 42 |
|
五角形把手
 |  | JB3717.22-85(Z64-7) | d | l | D | L | | M5 | 8 15 20 | 25 | 20 | | M6 | 15 20 25 30 35 | 32 | 24 | | M8 | 15 25 30 35 45 | 40 | 28 | | M10 | 20 30 35 40 50 | 50 | 34 | | M12 | 25 30 35 40 50 | 63 | 38 |
|
直纹把手
 |  | QB8285.6-98 | d | D | L | l | | M4 | 16 | 11 | 10 15 | | M5 | 20 | 13 | 10 16 25 40 | | M6 | 25 | 18 | 16 25 40 | | M8 | 32 | 18 | 16 25 40 |
|
波纹把手
 |  | | d | D | l | | 10 | 50 | 29 | | 12 | 70 | 33 | | 12 | 80 | 40 | | 14 | 100 | 44 |
|
六角星形把手
 |  | | M | D | d | H | L | | 8 | 32 | 18 | 24 | 14 | | 10 | 40 | 20 | 28 | 16 | | 12 | 50 | 26 | 32 | 18 | | 16 | 65 | 32 | 34 | 20 |
|
三角把手
 |  | QB8252.4-98 | d | D | l | | M4 | 20 | 10 16 20 25 | | M5 | 25 | 16 20 25 30 | | M6 | 32 | 16 20 25 30 | | M8 | 40 | 16 20 25 25 30 |
|
五角亚光把手
 |  | |
三棱形把手
 |  | QB8252.5-98 |
捏 手
 |  | JB1362-73
|
