制鞋机器 特供 DS-603万能机械液压压合机 制鞋压底机

DS-603**液压压合机

Universal Sole Attaching Machine

本机适用于男女鞋任意高度胶粘压合。

Used to glue and bind men’s and women’s shoes at any height.

主要特点 FEATURES

1. 前后压头压力采用液压联通器自动平衡，使前后压着力均匀。

2. 鞋前部位压合台面任意可调，鞋翘度可任意贴合。

3. 后靠可抱住任何鞋跟，自动可调，压合时鞋跟不会位移。

4. 铰链式前压座及橡胶插片、拉簧联合作用，使男女鞋均翘度合适，压底力均匀，压合牢固。

5. 插片顺序动作，可有效提高压合质量。

1. The pressure of front and rear pressure heads balances automatically through hydraulic connecting vessel, which makes front and back press forces homogeneous.

2. The pressing table top for front part of shoes is adjustable and shoe angularity can be bonded freely.

3. The backing stand is adjustable and can hold any shoe heel, which ensures shoe heel will not move aside while pressing and binding.

4. The joint effect of hinged front pressing set, rubber plug-in strip and tension spring makes the angularity of shoes proper and sole-pressing force homogeneous and firm.

5. Insert rubber plates act in order, which can improve the attaching effect greatly.

技术参数TECHNICAL PARAMETERS

功    率(Power)：1.5kw

电源电压(Power Supply Voltage)：380V

机器净重(Machine Net Weight)：800kg

包装重量(Package Weight)：860kg

外形尺寸(External Dimensions)：1070×600×1900(mm)

外包装尺寸(Package Dimensions)：1180×720×2100(mm)
