YT-527四柱油压裁断机

Hydraulic Four-column Cutting Machine

本机用于皮革、橡胶、塑料、纸板、布料等多种物料的裁断作业。

The machine can be used for cutting of various materials including leather, rubber, plastic, cardboard and cloth.

主要特点 FEATURES

1. 双油缸，精密四柱自动平衡连杆结构，确保上下工作台面平衡精度，确保每个裁断点受力相同。

2. 特有设定构造，附微调保护装置，灵活调设裁断高度和裁断力度，能延长裁刀和裁断胶板的使用寿命。
3. 主轴采用中央自动循环润滑系统，无人工疏忽打油而使机件损坏之顾虑，更有效确保机器耐用度。
1. Dual oil pumps, and precise 4-column automatic equilibrium joint structure, ensure the equilibrium of the worktable and same stress of every cutting position.

2. Exclusive setting structure with trimming device makes the best cutting setting of height and depth, and prolongs working life of the cutting knife and cutting board.

3. Central automatic lubricate system in principal axis to ensure the machining precise and improve its durability.

技术参数TECHNICAL PARAMETERS

功    率(Power)：2.2kw

电    压(Voltage)：380V

净    重(N.W.)：2100kg

毛    重(G.W.)：2150kg

机器尺寸(Machine Dimensions)：2300×1100×1450(mm)

包装尺寸(Packing Dimensions)：2450×1250×1650(mm)
