主要尺寸 (mm) | 轴承 型号 | 额定负荷 (N) 静动 | 极限转速 (rpm) 脂润滑 油润滑 | 键槽 b t1 | 重量 (kg) (参考) | |||||||
d | D | L | r | e | ||||||||
19 | 70 | 36 | 1.1 | 1.5 | 150752904k1 | 7800 | 7800 | 7000 | 9500 | 6 | 2.8 | 0.82 |
70 | 36 | 1.1 | 2.0 | 200752904k1 | 7800 | 7800 | 7000 | 9500 | 6 | 2.8 | 0.82 | |
70 | 36 | 1.1 | 3.0 | 300752904k1 | 7800 | 7800 | 7000 | 9500 | 6 | 2.8 | 0.82 | |
22 | 53.5 | 32 | 1.1 | 0.65 | 70752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 |
53.5 | 32 | 1.1 | 0.75 | 80752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 1.0 | 100752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 1.25 | 130752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 1.5 | 150752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 1.75 | 180752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 2.0 | 200752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 2.5 | 250752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 3.0 | 300752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 3.5 | 350752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 4.0 | 400752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 4.25 | 430752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 4.5 | 450752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
53.5 | 32 | 1.1 | 5.0 | 500752904 | 50900 | 61300 | 8500 | 11000 | 6 | 2.8 | 0.35 | |
61.8 | 34 | 1.1 | 0.75 | 80752904k | 71000 | 83000 | 7500 | 9500 | 6 | 2.8 | 0.5 | |
61.8 | 34 | 1.1 | 1.0 | 100752904k | 71000 | 83000 | 7500 | 9500 | 6 | 2.8 | 0.5 | |
61.8 | 34 | 1.1 | 1.25 | 130752904k | 71000 | 83000 | 7500 | 9500 | 6 | 2.8 | 0.5 | |
61.8 | 34 | 1.1 | 1.5 | 150752904k | 71000 | 83000 | 7500 | 9500 | 6 | 2.8 | 0.5 | |
61.8 | 34 | 1.1 | 2.0 | 200752904k | 71000 | 83000 | 7500 | 9500 | 6 | 2.8 | 0.5 | |
61.8 | 34 | 1.1 | 2.5 | 250752904k | 71000 | 83000 | 7500 | 9500 | 6 | 2.8 | 0.5 | |
61.8 | 34 | 1.1 | 3.0 | 300752905k | 71000 | 83000 | 7500 | 9500 | 6 | 2.8 | 0.5 | |
24 | 61.8 | 34 | 1.1 | 0.75 | 80752905y1 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 |
61.8 | 34 | 1.1 | 1.0 | 100752905y1 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 | |
61.8 | 34 | 1.1 | 1.25 | 130752905y1 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 | |
61.8 | 34 | 1.1 | 1.5 | 150752905y1 | 71000 | 83000 | 7500 | 9500 | 8 | 3.3 | 0.5 |
